Model number : UP-200KF
Wave length :1064nm
Output power :200W
Maximum pulse energy : 70J
Peak power :7kw
Pulse width :0.15-15ms
Pulse repetition rate: 1-50Hz
Unit time continuous pulse :100ms/S
The cylinder methods : Precise energy separation or high-speed time splitting
Closed loopfeedback control : Reak-time control power feedback of any waveform
Energy fluctuation line :<+(-)2%
Spectral : <(=)3
Positioning way :Laser diode red light indicator (The CCD orientation)
Cooling way :The extemal water
The power consumption of the device :8KW
The power requirements :AC380V+(-)15%50-60HZ
